CNC Machining for Aerospace Components

CNC milling capacity up to 20” W × 48” L × 24” H, ideal for aerospace brackets, mounting plates, and structural aluminum components requiring complex 3D geometries and tight repeatability.

Brand: Fadal
Model: VMC 4020-906-1

Capacity:
20" W × 48" L x 24" H

3- and 5-axis CNC milling up to 32” W × 70” L × 32” H, supporting machining of airframe structures, composite tooling, and satellite components with precision surfaces and multi-axis contouring.

Brand: YCM
Model: TV-188 B

Capacity:
32" W × 70" L x 32" H

Precision milling capacity of 35” W × 102” L × 35” H, enabling production of large aerospace panels, housings, and bulkhead components in aluminum, stainless, and titanium.

Brand: YCM
Model: TV 2610 B

Capacity:
9" W × 48" L x 18" H

Manual turning capacity up to 15” OD × 45” L, supporting aerospace shafts, actuator pins, and precision housings. Ideal for prototype work, secondary operations, and repair machining.

Brand: Kingston
Model: HJ-1700

Capacity:
15" OD × 45" L

Manual turning capacity up to 20” OD × 100” L, enabling precision aerospace parts manufacturing for long shafts, structural torque tubes, and oversized aerospace components.

Brand: Kingston
Model: HR-3000

Capacity:
20" OD x 100" L

Manual turning capacity up to 22” OD × 36” L, providing aerospace component machining services for medium-length parts such as bearing collars, coupling housings, and landing gear fittings.

Brand: Warner & Swasey
Model: 3-A

Capacity:
22" OD × 36" L

Manual turning capacity up to 20” OD × 120” L, supporting Inconel and titanium aerospace machining for extended shafts, torque tubes, and elongated structural components. This long-bed capability ensures straightness and precision across oversized aerospace parts and repair work.

Brand: Monarch
Model: 20-CM

Capacity:
20" OD × 120" L

Manual turning capacity up to 22” OD × 96” L, delivering AS9100 precision machining for large aerospace shafts, heavy housings, and oversized structural components. Suited for both new builds and repair machining where rugged performance and documented compliance are required.

Brand: Monarch
Model: 22-M

Capacity:
22" OD × 96" L

Manual turning capacity up to 24” OD × 120” L, extending our CNC machining for aerospace capabilities to oversized shafts, elongated torque tubes, and large structural components. This machine provides the reach and rigidity needed for long-bed aerospace turning and heavy repair work.

Brand: Axelson
Model: A25

Capacity:
24" OD × 120" L

Manual turning capacity up to 22.5” OD × 96” L, supporting precision aerospace parts manufacturing for medium-to-large shafts, coupling housings, and structural components. This machine provides the rigidity and accuracy required for both production and aerospace repair machining.

Brand: Monarch
Model: #20

Capacity:
22.5" OD × 96" L

Manual turning capacity up to 15” OD × 45” L, providing aerospace component machining services for small-to-medium parts, prototypes, and repair components. Well-suited for actuator pins, bearing housings, and short-length aerospace shafts that require accuracy and quick turnaround.

Brand: Clausing
Model: 15

Capacity:
15" OD × 45" L

Manual milling capacity up to 10” W × 50” L × 20” H, supporting Inconel and titanium aerospace machining for slotting, drilling, facing, and precision repair work. Ideal for brackets, tooling plates, and small housings, this mill provides versatility for both prototype and production aerospace applications.

Brand: Wilton
Model: Series II

Capacity:
10" W × 50" L × 20" H

Manual milling capacity up to 9” W × 48” L × 18” H, providing AS9100 precision machining for prototype parts, slotting, drilling, and detailed aerospace component repair. Well-suited for brackets, tooling inserts, and small structural parts requiring accuracy and repeatability.

Brand: Bridgeport
Model: Series II

Capacity:
9" W × 48" L × 18" H

Deep-hole drilling capacity up to 23.6” OD × 236.4” L, supporting Inconel and titanium aerospace machining for long tubular components, structural shafts, and aerospace torque tubes. This capability delivers precision bores and exceptional straightness required for flight-critical applications.

Brand: UNISIG
Model: B600-6M

Capacity:
23.6" OD × 236.4" L

Deep-hole drilling capacity up to 16” OD × 140” L, providing AS9100 precision machining for aerospace tubular components, hydraulic cylinders, and structural shafts. This service ensures straight, concentric bores and reliable accuracy for mission-critical aerospace applications.

Brand: UNISIG
Model: BTA_100_B500

Capacity:
16" OD × 140" L

Deep-hole drilling capacity up to 16” OD × 140” L, extending our CNC machining for aerospace capabilities to long shafts, actuator housings, and tubular structural components. This machine delivers rugged boring performance with precision straightness, ensuring reliability in demanding aerospace applications.

Brand: UNISIG
Model: BTA_1000_B500

Capacity:
16" OD × 140" L

Precision honing capacity up to 18” OD × 144” L, providing aerospace component machining services for long shafts, hydraulic cylinders, and tubular aerospace structures. This capability ensures superior surface finishes and tight bore tolerances required for flight-critical performance.

Brand: Ohio Tool Works
Model: OTW-5000-30-15

Capacity:
18" OD × 144" L

Precision honing capacity up to 15” OD × 60” L, supporting Inconel and titanium aerospace machining for medium-length components such as actuator housings, landing gear cylinders, and structural shafts. This process delivers accurate bore finishes and concentricity essential for aerospace reliability.

Brand: Ohio Tool Works
Model: OTW-9000-15-1.5

Capacity:
15" OD × 60" L
